EL900-A-N-1-A - Hardened Media Convertor - 20Km, Single Mode (SC) - 1310nm, 10-48VDC (DC Terminal Block)

EL900-A-N-1-A - Hardened Media Convertor - 20Km, Single Mode (SC) - 1310nm, 10-48VDC (DC Terminal Block)

EL900-A-N-1-A

$418.71 USD
$418.71 USD
Sale Sold out

EL900-A-N-1-A - Hardened Media Convertor

20Km, Single Mode (SC) - 1310nm, 10-48VDC (DC Terminal Block)

Please note that the EL900-A-N-1-A is a special order product, and if you decide to purchase this product, it cannot be cancelled, and it is non-returnable.

Lead time is approximately 4-8 weeks. By purchasing this product on etherwanshop.com, you agree to the terms that this item is non-cancellable and non-returnable (NCNR).

If you have any question please contact us at info@etherwanshop.com

EL900-A-N-1-A provides media conversion between 10/100BASE-T and Single Mode (SC) - 20Km (1310nm) fiber. Built specifically for mission-critical applications in harsh environments, the EL900's hardened design features high shock & vibration resistance, electrical noise immunity, wide operating temperature range from -40°C to 75°C, and ruggedized aluminum housing. With triple power inputs, link down alarming, Link-Fault-Pass-Through and a wide range of fiber connectivity options, the EL900 is the ideal media converter for harsh environments.

  • Design and certified for Class I, Division 2 electrical equipment
  • Link Fault Pass Through (LFPT)
  • Alarms for power and link failure
  • Highly qualified for explosive environmental applications and certified by UL with ISA12.12.01 Class I, Division 2 classified for use in hazardous locations
  • -40°C to 75°C wide operating temperature range design is suitable for installation in outdoor cabinet
  • LFPT function let network operators be aware of network connection status
  • When fiber link is down, LFPT function will turn down Ethernet port to inform connected device that the link is down and vise versa

Casing
Aluminum Case

Dimensions
50mm x 110mm x 135mm (W x D x H)
1.97" x 4.33" x 5.31"

Weight
0.8Kg (1.76lbs.)

Installation
DIN-Rail (top hat type 35mm) or panel mounting

Click here for additional information

For detailed specifications, download the datasheet here

16 in stock

View full details

More Information

POE TYPE: None
POWER INPUT: 10-48VDC (DC Terminal Block)
ALARM RELAY: Yes
MOUNT TYPE: DIN-Rail
REDUNDANT POWER: Yes
PRODUCT CLASS: Industrial/Hardened
OPERATING TEMPERATURE RANGE: -40 to 75°C (-40 to 167°F) Tested @ -40 to 85°C (-40 to 185°F)
MANAGEMENT TYPE: Unmanaged
FIBER PORTS: 1
FIBER DISTANCE: 20Km
FIBER/SFP CONNECTOR: SC
10/100 PORTS: 1
INDUSTRY STANDARDS: Class 1 Division 2 (C1D2), NEMA-TS2, UL 60950
