EPHX-24-60 Industrial Power Supply | 24V 60W DIN Rail

The EtherWAN EPHX-24-60 is a compact DIN rail industrial power supply that converts AC input to a regulated 24V DC output for industrial equipment and control cabinets. It delivers 60W at 2.5A and is 35 mm wide, making it a practical fit where cabinet space is limited. The unit is Phoenix Contact part 2902992.

Features

• 24V DC power: Supplies up to 60W and 2.5A for compatible equipment.
• Wide AC input: Accepts 85–264V AC.
• Compact DIN rail mounting: Measures 35 × 90 × 84 mm (1.38 × 3.54 × 3.31 in), width × height × depth.
• Efficient operation: Typical efficiency is 88% at 120V AC and 90% at 230V AC, with less than 0.3W no-load power consumption.
• Industrial temperature range: Operates from −25 to 70°C (−13 to 158°F). Output must be derated above 55°C (131°F).
• Built-in protection: Includes short-circuit protection and an internal input fuse.

Common applications

Powering compatible 24V DC equipment in industrial automation, building controls, and network control cabinets.

Common Questions

What equipment can the EPHX-24-60 power?
It supplies 24V DC at up to 2.5A (60W) for compatible equipment, such as industrial controllers and network devices. Check your equipment’s voltage and power requirements before ordering.

Can it deliver the full 60W at 70°C (158°F)?
No. It delivers its rated 60W up to 55°C (131°F). Above that temperature, the available output decreases.

Can it be installed outdoors?
The power supply is IP20 rated and designed for DIN rail installation inside a suitable enclosure. It should not be exposed directly to weather.

Is an AC power cord included?
No. The PC-183-72 power cord is sold separately for suitable North American 125V AC installations. Its stripped leads may need to be trimmed and prepared to meet this power supply’s 8 mm input-terminal requirement.

For detailed specifications, download the datasheet here
