EPOW-24-60 - Hardened Power Supply 60W, 24VDC 100-277 VAC Input, NEMA-TS2 rated, 0-11.1A w/ Open Wire (US Plug)

Hardened Power Supply 24V 60W

With a wide operating temperature range of -40 to 75°C (-40 to 167°F) and built with an aluminum fanless design, EtherWAN’s EPOW-24-60 is a 24V 60W hardened power supply designed to operate in the most extreme environments. The EPOW-24-60 has a 60W power budget and built in over-voltage and short-current protection, making it a perfect and reliable solution for PoE applications.

• Active built-in PFC for max power distribution efficiency
• Constant voltage across output terminal
• Complies with NEMA TS1 & TS2 electrical and temperature requirements for traffic control equipment
• Easy installation with pre-attached cables and mounting holes
• Wide operating temperature range -40 to 75°C (-40 to 167°F)
• Fanless operation
• IP67 total dust protection and water resistance

Casing Material
Aluminum

IP Rating
IP67 (Dust Tight and Waterproof)

Dimensions
180mm x 44mm x 32mm (W x D x H)
7.09" x 1.74” x 1.26"

Weight
1.32lbs (0.6kg)

Installation Type
Wall mounting

Click here for additional information

For detailed specifications, download the datasheet here
